Description
Product Details
Schneider Electric LC1D TeSys D Contactors.
TeSys D Contactors from Schneider Electric combine long mechanical and electrical life to offer a high reliable contactor. The range has been designed for integration in control systems and can be used to create motor starters for any type of application. The TeSys D contactors offer quick simple setup while maintaining compliance with international standards.
Features and Benefits.
-
- Built-in auxiliary contacts for added switching capability.
-
- Screw connections: IP20 finger-safe terminals with both North American and International terminal markings.
-
- Can be panel mounted with screws or DIN Rail mounted.
-
- Bidirectional peak limiting diode suppressor to protect the coil.
-
- Easily installed accessories.
- Flexible control circuit to suit a wide range of applications.
What does the utilisation category AC1 and AC3 mean for the TeSys contactors?
-
- Contactor utilisation categories define the current making and breaking values, based on the type of load to be controlled and the operating cycle conditions.
-
- AC-1: This applies to all AC devices with a power factor of at least 0.95. Example of use: resistive load, heating, distribution.
- AC-3: This applies to squirrel cage motors where breaking occurs while the motor is running. Example of use: all squirrel cage motors, lifts, escalators, conveyors, bucket elevators, compressors, pumps, mixers, air conditioning units.
What accessories are available?
-
- Auxiliary contact blocks with serrated wiping action.
-
- Front mount dust tight auxiliary contact blocks.
-
- Pneumatic time delay blocks.
-
- Transient voltage surge suppressors.
-
- Interface modules and electronic timers.
- Mechanical latching blocks.
Is the TeSys D range a double break pole type contactor?
- Yes, the Tesys D range uses linear translation movement that provides double breaking of the poles.
Specification
| Attribute | Value |
| Coil Voltage | 42 V ac |
| Number of Poles | 3 |
| Contact Current Rating | 18 A |
| Normal State Configuration | 3NO |
| Contact Voltage Rating | 690 V ac/dc |
| Series | LC1D |
| Range | TeSys D |
| Number Of Auxiliary Contacts | 2 |
| Auxiliary Contact Configuration | 1NO + 1NC |
| Terminal Type | Screw |
| Width | 45mm |
| Depth | 86mm |
| Length | 77mm |
Additional information
| brand | SCHNEIDER |
|---|
